Neighbour Ranks

On this page

A rank says where a team sits, but not how close the teams around it are. This recipe puts one team in the middle of an 11-row table, the five teams ranked just above it and the five just below, so the gap to its neighbours shows next to the number.

It uses three sdvplotR helpers: gt_sdv_logos() for the logos and names, gt_color_ranks() for the rank column and gt_highlight_cells() for the focal row.

library(sdvplotR)
library(gt)

The data

cfbfastR’s load_espn_cfb_team_summaries() reads the SportsDataverse season summary release: one row per FBS team, with each metric next to a _rank column.

summaries <- as.data.frame(cfbfastR::load_espn_cfb_team_summaries(2025))
dim(summaries)
#> [1] 136 788
head(grep("_rank$", names(summaries), value = TRUE))
#> [1] "playsgame_off_rank"      "TEPA_off_rank"
#> [3] "EPAgame_off_rank"        "EPAplay_off_rank"
#> [5] "EPAdrive_off_rank"       "early_down_EPA_off_rank"

Not every metric has a rank, so check the three this recipe uses. Rank 1 is the best team in each one: the highest net and offensive EPA per play, and the fewest EPA per play allowed on defense.

metrics <- c(
  net_adj_epa = "Net adj. EPA/play",
  EPAplay_off = "Offense EPA/play",
  EPAplay_def = "Defense EPA/play"
)
stopifnot(all(paste0(names(metrics), "_rank") %in% names(summaries)))

The window

Sort by the rank column and take the 11 rows centred on the team. Near the top or bottom of the table there are not five teams on both sides, so the window slides instead of shrinking: it stays 11 rows and the focal team moves off centre.

neighbours <- function(data, team, metric, k = 5) {
  data <- data[order(data[[paste0(metric, "_rank")]]), ]
  i <- match(team, data$pos_team)
  first <- min(max(i - k, 1), nrow(data) - 2 * k)
  rows <- data[first:(first + 2 * k), ]
  data.frame(
    rank = rows[[paste0(metric, "_rank")]],
    team = rows$pos_team,
    value = rows[[metric]]
  )
}

focal <- "Illinois"
neighbours(summaries, focal, "net_adj_epa")
#>    rank          team     value
#> 1    30    Louisville 0.1487155
#> 2    31 South Florida 0.1463640
#> 3    32      Virginia 0.1397002
#> 4    33           TCU 0.1341972
#> 5    34    Iowa State 0.1333091
#> 6    35      Illinois 0.1278535
#> 7    36 East Carolina 0.1276368
#> 8    37     Tennessee 0.1206984
#> 9    38        Toledo 0.1150806
#> 10   39    Pittsburgh 0.1124272
#> 11   40  Old Dominion 0.1124005

The table

The rank colors use the whole league as their domain (1 to the number of teams), not the 11 rows on show, so a mid-table window reads as mid-table. The focal team’s name and value are filled with gt_highlight_cells(), which takes a logical mask the same shape as the columns it fills.

neighbour_table <- function(data, focal_team, metric, label) {
  win <- neighbours(data, focal_team, metric)
  is_focal <- win$team == focal_team
  gt(win) |>
    tab_header(title = label) |>
    gt_sdv_logos(team, league = "cfb", height = 20, include_name = TRUE) |>
    fmt_number(value, decimals = 3) |>
    cols_label(rank = "Rank", team = "Team", value = "Value") |>
    gt_theme_sdv_team(team = focal_team, league = "cfb", density = "compact") |>
    gt_color_ranks(rank, domain = c(1, nrow(data))) |>
    gt_highlight_cells(c(team, value), cbind(is_focal, is_focal), bold = TRUE)
}

neighbour_table(summaries, focal, "net_adj_epa", metrics[["net_adj_epa"]])

Rank	Team	Value
Net adj. EPA/play
30	Louisville	0.149
31	South Florida	0.146
32	Virginia	0.140
33	TCU	0.134
34	Iowa State	0.133
35	Illinois	0.128
36	East Carolina	0.128
37	Tennessee	0.121
38	Toledo	0.115
39	Pittsburgh	0.112
40	Old Dominion	0.112

Three metrics side by side

The same function, once per metric, laid out with gt_grid().

tables <- lapply(names(metrics), function(m) {
  neighbour_table(summaries, focal, m, metrics[[m]])
})
gt_grid(
  tables,
  ncol = 3,
  gap = 12,
  title = paste(focal, "and its neighbours"),
  subtitle = "2025 FBS season, five teams either side by rank",
  caption = "Data: cfbfastR::load_espn_cfb_team_summaries()"
)

Illinois and its neighbours

2025 FBS season, five teams either side by rank

Rank	Team	Value
Net adj. EPA/play
30	Louisville	0.149
31	South Florida	0.146
32	Virginia	0.140
33	TCU	0.134
34	Iowa State	0.133
35	Illinois	0.128
36	East Carolina	0.128
37	Tennessee	0.121
38	Toledo	0.115
39	Pittsburgh	0.112
40	Old Dominion	0.112

Rank	Team	Value
Offense EPA/play
29	Eastern Michigan	0.120
30	SMU	0.119
31	UAB	0.116
32	Army	0.113
33	Ohio	0.111
34	Illinois	0.111
35	Penn State	0.109
36	Temple	0.106
37	Texas	0.104
38	NC State	0.100
39	Utah State	0.093

Rank	Team	Value
Defense EPA/play
94	Marshall	0.108
95	North Texas	0.110
96	Louisiana	0.111
97	Mississippi State	0.112
98	NC State	0.114
99	Illinois	0.117
100	San José State	0.118
101	Kent State	0.118
102	App State	0.119
103	Texas State	0.119
104	Tennessee	0.121

Data: cfbfastR::load_espn_cfb_team_summaries()

Checking the window

A team more than five places from either end is row 6 of 11. Check it for every team on all three metrics, then look at the rows the top and bottom teams land on.

row_of <- function(team, metric) {
  match(team, neighbours(summaries, team, metric)$team)
}
n <- nrow(summaries)

for (m in names(metrics)) {
  ranks <- summaries[[paste0(m, "_rank")]]
  rows <- vapply(summaries$pos_team, row_of, integer(1), metric = m)
  stopifnot(all(rows[ranks > 5 & ranks <= n - 5] == 6))
}

ranks <- summaries$net_adj_epa_rank
edges <- summaries$pos_team[order(ranks)][c(1:6, (n - 5):n)]
data.frame(
  team = edges,
  rank = ranks[match(edges, summaries$pos_team)],
  row = unname(vapply(edges, row_of, integer(1), metric = "net_adj_epa"))
)
#>             team rank row
#> 1        Indiana    1   1
#> 2     Ohio State    2   2
#> 3     Notre Dame    3   3
#> 4          Miami    4   4
#> 5     Texas Tech    5   5
#> 6         Oregon    6   6
#> 7      Charlotte  131   6
#> 8        Buffalo  132   7
#> 9          Akron  133   8
#> 10    Ball State  134   9
#> 11   Sam Houston  135  10
#> 12 Massachusetts  136  11
