Creating Faceted Tables

Saiem Gilani
@saiemgilani @saiemgilani

Source: vignettes/grid_tables.Rmd
grid_tables.Rmd
On this page

Nobody likes a long table. Put 25 rows next to a handful of columns and you get an image twice as tall as it is wide, mostly empty, with half the values scrolled off the bottom of a feed. The fix is to fold that one tall table into two shorter ones and set them side by side.

gt_grid() does that the direct way: build each block as a normal gt table, put the tables in a list, and gt_grid() arranges the list under one shared header and footer. Nothing gets reshaped, so every block is a real table you can style with the rest of the package. This article builds a top 25 of men’s college basketball for 2025-26 that way, and uses two more functions along the route: gt_color_ranks(), which colors a column by its values, and gt_spotlight(), which lights a set of rows and dims the rest.

The games are hoopR’s ESPN box scores. gt_grid(), gt_color_ranks() and gt_spotlight() come from Andrew Weatherman’s gtUtils, and this article follows his faceted-tables example.

1. The data: a top 25 by efficiency margin

We rank every Division I team by efficiency margin, points scored minus points allowed per 100 possessions, over its games against other Division I teams, tournaments included. The margin is raw, not adjusted for opponents. Each team also gets its national rank on offense and on defense.

d1 <- sdv_teams("mbb")

box <- hoopR::load_mbb_team_box(seasons = 2026) |>
  mutate(poss = field_goals_attempted - offensive_rebounds + total_turnovers + 0.475 * free_throws_attempted)

ratings <- box |>
  # Division I against Division I only
  filter(team_id %in% d1$team_id, opponent_team_id %in% d1$team_id) |>
  inner_join(
    select(box, game_id, opponent_team_id = team_id, opp_poss = poss),
    by = c("game_id", "opponent_team_id")
  ) |>
  summarise(
    off = 100 * sum(team_score) / sum(poss),
    def = 100 * sum(opponent_team_score) / sum(opp_poss),
    .by = team_id
  ) |>
  mutate(
    net = off - def,
    off_rank = min_rank(desc(off)),
    def_rank = min_rank(def),
    team = d1$location[match(team_id, d1$team_id)],
    conf = d1$conference[match(team_id, d1$team_id)]
  )

data <- ratings |>
  arrange(desc(net), team) |>
  mutate(rk = row_number()) |>
  filter(rk <= 25) |>
  select(rk, team, conf, off_rank, def_rank, net)

The team names are ESPN’s school names ("Michigan", "Iowa State"), and gt_sdv_logos() resolves them as they are, so they go into the table untouched and get their logos later. Sorting on team after net breaks any tie the same way on every rebuild.

Before splitting anything, two values are computed once, off the full table.

rank_domain <- c(1, nrow(ratings))

sizes <- c(13, 12)
chunks <- split(data, rep(seq_along(sizes), sizes))

rank_domain is the full range of the national ranks, 1 to the number of Division I teams, and it matters because of how coloring works. A color scale is built from whatever data it sees. If each block builds its own scale, block one maps its colors to the ranks it happens to hold and block two to its own, so the same rank lands on a different shade depending on which block a team falls in. Fixing the domain once and handing it to both blocks keeps one scale across the whole table, and anchors it to the whole country rather than the top 25.

sizes sets the split: 13 rows in the first block and 12 in the second. rep(seq_along(sizes), sizes) turns c(13, 12) into 13 1s followed by 12 2s, and split() cuts the data on that. For three blocks, use c(9, 8, 8).

2. Coloring a column by rank

Inside each block we color the two national-rank columns with gt_color_ranks().

gt_color_ranks(c(off_rank, def_rank), domain = rank_domain)

The arguments worth knowing:

  • palette: either a vector of hex colors or a paletteer palette named as "package::palette". The default is a 5-color green-to-red ramp, so a low value (a high rank) reads green.
  • domain: the value range mapped onto the palette. Left NULL, it is taken from the column itself. We pass rank_domain so both blocks share a scale.
  • reverse: flip the palette, for when high numbers should be green instead.
  • pal_type: "discrete" or "continuous", which only matters when you hand it a paletteer palette.
  • na_color: fill for missing values, white by default.
  • autocolor_text: sets the text color for contrast against the fill, so dark cells get light text automatically. On by default.

It colors values as they are and does not rank for you, so it works on any numeric column. Reach for a paletteer palette when you want something other than the default ramp:

gt_color_ranks(c(off_rank, def_rank),
  domain = rank_domain,
  palette = "viridis::mako", pal_type = "continuous", reverse = TRUE
)

3. One table, applied to each block

Every block is a gt table, so we write the recipe once and lapply() it over the chunks. None of this is grid-specific; it is the same table you would build for a single frame.

block <- function(x) {
  gt(x) |>
    gt_theme_swiss() |>
    cols_hide(conf) |>
    cols_align(columns = -team, align = "center") |>
    cols_align(columns = team, "left") |>
    cols_label(
      rk = "", team = "Team",
      off_rank = "Off.", def_rank = "Def.", net = "Margin"
    ) |>
    cols_width(team ~ px(140), c(off_rank, def_rank) ~ px(46), net ~ px(62)) |>
    tab_spanner(columns = c(off_rank, def_rank), label = "Nat'l rank") |>
    fmt_number(net, decimals = 1, force_sign = TRUE) |>
    gt_color_ranks(c(off_rank, def_rank), domain = rank_domain) |>
    gt_sdv_logos(team, league = "mbb", height = 20, include_name = TRUE) |>
    gtExtras::gt_add_divider(team, color = "white", weight = px(10)) |>
    tab_options(
      data_row.padding = px(6),
      table_body.hlines.style = "solid",
      table_body.hlines.color = "black",
      table_body.hlines.width = px(1)
    )
}

tbls <- lapply(chunks, block)

gt_color_ranks(..., domain = rank_domain) is the shared scale from earlier. gt_sdv_logos(team, ..., include_name = TRUE) puts each school’s logo in front of its name. gt_add_divider() (from gtExtras) adds a white gap after the team column so the numbers do not crowd the logos. cols_hide(conf) keeps the conference in the data but out of the table; the last section uses it.

4. Laying it out with gt_grid

Now the list goes to gt_grid().

gt_grid(tbls,
  ncol = 2, gap = 24,
  title = "The top 25 by efficiency margin",
  subtitle = "Men's college basketball, 2025-26, games between Division I teams",
  title_style = list(
    font = "Oswald", size = 34, transform = "uppercase",
    margin_bottom = -4
  ),
  subtitle_style = list(italic = TRUE, color = "#6A6A6A"),
  caption = "Margin is points scored minus points allowed per 100 possessions, not adjusted for opponents.",
  caption_style = list(align = "left"),
  source_note = "Data: ESPN box scores via hoopR",
  caption_rule = TRUE
)
The top 25 by efficiency margin
Men's college basketball, 2025-26, games between Division I teams
Team
Nat'l rank
 Margin
Off. Def.
1 Duke 4 2 +27.7
2 Gonzaga 13 1 +26.4
3 Arizona 11 6 +24.3
4 Michigan 8 8 +24.0
5 Iowa State 20 4 +23.2
6 Florida 7 19 +22.5
7 Illinois 1 61 +21.6
8 Houston 36 5 +21.5
9 Saint Louis 14 21 +20.9
10 High Point 12 38 +19.0
11 Saint Mary's 39 14 +19.0
12 Virginia 21 39 +17.5
13 Nebraska 61 13 +17.1
Team
Nat'l rank
 Margin
Off. Def.
14 UConn 52 17 +17.0
15 Purdue 2 162 +16.6
16 Louisville 27 49 +16.3
17 Akron 6 98 +16.1
18 St. John's 68 15 +15.9
19 Vanderbilt 9 99 +15.3
20 Utah State 23 72 +15.3
21 Michigan State 40 40 +15.1
22 Miami 38 60 +14.5
23 McNeese 69 27 +14.2
24 Miami (OH) 15 102 +14.1
25 Tennessee 49 43 +13.8
Margin is points scored minus points allowed per 100 possessions, not adjusted for opponents.
Data: ESPN box scores via hoopR

ncol sets how many tables go across, and the number of rows follows from the list length. gap is the space between them in pixels. There is also an align argument ("top", "center", "bottom") for when the blocks are different heights, which is common with an uneven split like ours.

The header and footer are set on the grid, not on the individual tables, so one title covers both blocks instead of a title stranded on each. title, subtitle, caption, and source_note are the four text slots. Setting caption, source_note, and caption_rule = TRUE together gives the 538-style split caption, and caption accepts md(), so links and bold text work.

Each text slot has a matching *_style list, and the keys are the same across all of them (see Styling Headers, Legends and Captions): font, size, color, weight, italic, spacing, transform, align, line_height, and the margin_* and padding_* keys. Anything you leave out keeps its default, so the title_style above changes only the font, size, transform and margin. margin_bottom = -4 pulls the subtitle up closer to the title.

Two more arguments are worth knowing. labels puts a short caption above each individual table (styled by label_style), which is handy for small multiples like one table per conference or per season. file writes the grid straight to a PNG, with bg, whitespace and zoom controlling that export.

5. Spotlighting rows across blocks

To make a point about one conference, we light its teams with gt_spotlight() and dim the rest. The conference is whichever has the most teams in the top 25, worked out from the data, with alphabetical order breaking a tie.

top_conf <- data |>
  count(conf) |>
  arrange(desc(n), conf) |>
  slice(1)
top_conf
#> # A tibble: 1 × 2
#>   conf                   n
#>   <chr>              <int>
#> 1 Big Ten Conference     5

gt_spotlight() reads a filter expression against each block’s own data, so it drops right into the block function. The wrinkle is that the conference’s teams fall across both blocks, and a block with no match at all would be left fully lit, so the highlight would look applied to one block and not the other. That is what if_none = "dim" handles: a block that matches nobody dims completely.

spot <- lapply(chunks, function(x) {
  block(x) |>
    gt_spotlight(
      rows = conf == top_conf$conf, if_none = "dim",
      accent_color = "darkred"
    )
})

gt_grid(spot,
  ncol = 2, gap = 24,
  title = paste(top_conf$conf, "has", top_conf$n, "of the top 25"),
  subtitle = "Men's college basketball, 2025-26, by efficiency margin",
  title_style = list(
    font = "Oswald", size = 34, transform = "uppercase",
    margin_bottom = -4
  ),
  subtitle_style = list(italic = TRUE, color = "#6A6A6A"),
  caption = "Margin is points scored minus points allowed per 100 possessions, not adjusted for opponents.",
  caption_style = list(align = "left"),
  source_note = "Data: ESPN box scores via hoopR",
  caption_rule = TRUE
)
Big Ten Conference has 5 of the top 25
Men's college basketball, 2025-26, by efficiency margin
Team
Nat'l rank
 Margin
Off. Def.
1 Duke 4 2 +27.7
2 Gonzaga 13 1 +26.4
3 Arizona 11 6 +24.3
4 Michigan 8 8 +24.0
5 Iowa State 20 4 +23.2
6 Florida 7 19 +22.5
7 Illinois 1 61 +21.6
8 Houston 36 5 +21.5
9 Saint Louis 14 21 +20.9
10 High Point 12 38 +19.0
11 Saint Mary's 39 14 +19.0
12 Virginia 21 39 +17.5
13 Nebraska 61 13 +17.1
Team
Nat'l rank
 Margin
Off. Def.
14 UConn 52 17 +17.0
15 Purdue 2 162 +16.6
16 Louisville 27 49 +16.3
17 Akron 6 98 +16.1
18 St. John's 68 15 +15.9
19 Vanderbilt 9 99 +15.3
20 Utah State 23 72 +15.3
21 Michigan State 40 40 +15.1
22 Miami 38 60 +14.5
23 McNeese 69 27 +14.2
24 Miami (OH) 15 102 +14.1
25 Tennessee 49 43 +13.8
Margin is points scored minus points allowed per 100 possessions, not adjusted for opponents.
Data: ESPN box scores via hoopR

This is why conf stayed hidden rather than dropped: gt_spotlight() filters on it even though the column is never drawn. rows also accepts plain row numbers, like rows = 1:5, when you want to highlight by position.

The rest of its arguments control the look:

  • accent_color: draws a bar on the left edge of each lit row. Supplying a color is what turns the bar on. accent_width sets its thickness, and accent_column moves it to a different column.
  • dim_color: the text color for the muted rows. By default it is worked out from the table’s background, as faint as it can be while still passing WCAG AA contrast (4.5:1), so the dimmed teams stay readable on a light or a dark theme. Setting it to NULL emphasizes the chosen rows without dimming the others.
  • fill, text_color, and bold: styling for the lit rows themselves.
  • columns: narrows the spotlight to some columns, dimming the rest of the row too, so only those cells stay at full strength.

Outside of grids, gt_spotlight() is useful on a single table any time you want one row or a small group highlighted.

Wrapping up

The pattern is the same both times: build a normal table, lapply() it over your chunks, and pass the list to gt_grid(). The only two faceting-specific habits are fixing your color domain once so the blocks agree, and using if_none = "dim" when a highlight lands in some blocks and not others. To keep a long table as one table instead, gt_snake() folds it into blocks; the rolling-window article uses it.
